Plate Type Heat Exchanger

A plate type heat exchanger is a type of heat exchanger that uses metal plates to transfer heat between two fluids. The fluids are separated by the plates and do not mix. The plates have a large surface area and create channels for the fluids to flow through. The plates are usually made of stainless steel and are pressed or welded together. The plates can have different patterns or corrugations to increase the heat transfer and reduce the fouling.

A plate type heat exchanger can have different configurations, depending on the number of fluids, the direction of flow, and the connection of the plates. Some common types of plate heat exchangers are:

-Gasketed plate heat exchanger :

The plates are brazed together with copper or nickel to form a compact and leak-proof unit. The brazing also enhances the heat transfer by creating turbulence in the fluids.

-Brazed plate heat exchanger :

The plates are welded together to form a durable and high-pressure unit. The welding eliminates the need for gaskets or brazing, but also makes the unit difficult to clean or repair.

- Welded plate heat exchanger:

The plates are welded together to form a durable and high-pressure unit. The welding eliminates the need for gaskets or brazing, but also makes the unit difficult to clean or repair.

-Semi-welded plate heat exchanger :

The plates are welded together to form a durable and high-pressure unit. The welding eliminates the need for gaskets or brazing, but also makes the unit difficult to clean or repair.

Problems & Solutions:

Some common problems in plate type heat exchangers are fouling, leakage, corrosion, and gasket failure. These problems can reduce the efficiency, performance, and lifespan of the heat exchanger. Some possible solutions are:

- Fouling:

The plates are welded together to form a durable and high-pressure unit. The welding eliminates the need for gaskets or brazing, but also makes the unit difficult to clean or repair.

- Leakage:

This is the loss of fluid from the heat exchanger due to cracks, holes, or improper sealing of the plates. Leakage can cause contamination of the fluids, loss of pressure, and reduced heat transfer. To prevent or reduce leakage, the plates should be inspected for damage, the gaskets should be replaced periodically, and the clamping force should be adjusted to ensure proper sealing.

- Corrosion:

This is the deterioration of the metal plates due to chemical or electrochemical reactions with the fluids or the environment. Corrosion can cause pitting, cracking, or perforation of the plates, which can lead to leakage or reduced heat transfer. To prevent or reduce corrosion, the materials of the plates should be compatible with the fluids and the operating conditions, the pH and oxygen levels of the fluids should be controlled, and corrosion inhibitors should be added if necessary.

- Gasket failure:

This is the degradation or damage of the rubber gaskets that seal the gaps between the plates. Gasket failure can cause leakage or reduced heat transfer. To prevent or reduce gasket failure, the gaskets should be made of suitable material for the fluids and the operating temperature, the gaskets should be stored properly before installation, and the gaskets should be replaced periodically.

How 3S ENGINEERING SOLUTIONS Can help?

We at 3S Engineering Solutions help our customers in sourcing HIGH quality PHE & its Spares. We also help our customers in selection of the most suitable PHE based on application demand. We help our customers in improving the efficiency by providing PHE Cleaning Services. We also provide all types of Gaskets, Plates, PHE Gasket Adhesive & Cleaning solutions.

In case you want to save costs, improve uptime & efficiency of the PHE, please feel free to contact us.
